Loading... Breezy 600

Wheel Lock Pull To Lock (quickie Style)

Name: Breezy 600: Wheel Lock Pull To Lock (quickie Style)
Manufacturer: Sunrise Medical
Wheel Lock Pull To Lock (quickie Style) parts diagram
(Click on image to enlarge)

NOTE: QUICKIE STYLE WHEEL LOCKS ARE NOT OFFERED ON THE BREEZY 600 BUT WILL MOUNT DIRECTLY USING THE WHEEL LOCK CLAMP.
Pos. Part # Description Price Buy
1 560500-QU HB PLASTIC COVER
$4.25
3 560126 .250 ID .312 OD BUSHING PLASTIC
$4.25
4 226125 1/4-28 X 1 1/8 BH C/S
$4.25
5 561028 1/4 NYLON WASHER
$4.25
6 550374 WHEEL LOCK SLIDE BLOCK 3 1/2” BLK
$9.00
7 106941 NUT AUTOMATION 1/4 -28 ROHS
$6.00
8 550659 CLAMP 1 1/4” RECESS HALF BLK
$10.00
9 550658 CLAMP 1 1/4" THREADED BLK
$10.00
10 107367 WASHER LOCK HI COLLAR 1/4 ROHS
$6.00
11 107032 SHCS 1/4-28 X 1 ROHS
$6.00
12 880916 GRADE AID PLATE W/WHL & HDWR R
$36.40
12 880917 GRADE AID PLATE W/WHL & HDWR L
$36.40
6, 12 880912 GRADE AID ASSM BLK R N/CLAMP
$60.00
6, 12 880913 GRADE AID ASSM BLK L N/CLAMP
$60.00
13 483027 1/4 x 1/4 ALUMINUM SPACER BLK
$4.25
14 226130 1/4-28 x 1 1/2 BH C/S
$4.25
8 - 11 107639 WHL LCK CLMP ASM
$32.00
8 - 12 880914 GRADE AID ASSM BLK R W/CLAMP
$70.00
8 - 12 880915 GRADE AID ASSM BLK L W/CLAMP
$70.00
1 - 7 883012 WHL LOCK PULL R W/O CLMP BLK- FORWARD CONFIG.
$42.00
1 - 7 883013 WHL LOCK PULL L W/O CLMP BLK- FORWARD CONFIG.
$42.00
1 - 7 881764 WHL LOCK PULL R REV N/ CLMP BLK- REVERSE CONFIG.
$39.78
1 - 7 881765 WHL LOCK L PULL REV N/ CLMP BLK- REVERSE CONFIG.
$39.78
1 - 11 881967 WHL LOCK PULL R W/ CLMP BLK- FORWARD CONFIG.
$51.86
1 - 11 881968 WHL LOCK PULL L W/ CLMP BLK- FORWARD CONFIG.
$51.86
1 - 11 881975 WHL LOCK PULL R REV W/CLMP BLK- REVERSE CONFIG.
$50.84
1 - 11 881976 WHL LOCK PULL L REV W/CLMP BLK- REVERSE CONFIG.
$50.84
1 - 11 901555 WHEEL LOCK PULL W/CLAMP BLK- PAIR, FORWARD CONFIG.
$82.62
1 - 11 901543 WHEEL LOCK PULL REV W/CLAMP BLK- PAIR, REVERSE CONFIG.
$82.62
1 - 7, 12 881756 WHL LOCK R PULL W/G.A. N/ CLMP BLK
$82.62
1 - 7, 12 881757 WHL LOCK L PULL W/G.A. N/ CLMP BLK
$82.62
1 - 11, 12 881971 WHL LOCK R PULL W/ G.A. W/CLMP BLK
$97.08
1 - 11, 12 881972 WHL LOCK L PULL W/ G.A. W/CLMP BLK
$97.08
1 - 11, 12 901558 WHEEL LOCK PULL W/GRADE AID W/CLAMP BLK- PAIR
$200.00
