Stem Mount, 14.322" Centers - 14"-20"

Name: Synergy Seat: Stem Mount, 14.322" Centers - 14"-20"
Manufacturer: Pride Mobility
Stem Mount, 14.322
(Click on image to enlarge)

*A1 - B6  Both assemblies contain identical parts. There are different part numbers for assembly purposes.
Pos. Part # Description Price Buy
A1 - B6 FRMASMB4809 STEM MOUNT, ASSY, 14"W-18"W, 14.322" CENTERS, SYNERGY SEAT
$264.27
A1 - B6 FRMASMB4810 STEM MOUNT, ASSY, 16"W-20"W, 14.322" CENTERS, SYNERGY SEAT
$264.27
A1 - A4 FRMASMB4657 STEM MOUNT PLATE, ASSY, SYNERGY SEAT, B-1360-002
$24.19
A1 DWR1360B009 MOUNTING BRACKET, STEM MOUNT PLATE, SYNERGY SEAT
$5.62
A2 DWR1005B215 T-NUT, BLACK, 5/16-18 X 2.75", W/3 HOLES, 0.74" TH, B-1005-215
$6.75
A3 SCRHHCS1246 SCREW, HHCS, BLACK ZINC, 5/16-18 X 1.25", GR 8, W/PATCH
$2.81
A4 DWR1600A052 SPACER, BLACK ZINC, STEEL, 0.328" ID X 0.50" OD X 0.20" TH, A-1600-052
$2.92
B1 - B6 FRMASMB6468 HORIZONTAL STEM SUPPORT, ASSY, 14"W-20"W, 14.322"CENTERS
$94.46
B1 DWR1360D007 HORIZONTAL STEM SUPPORT, 14"W-20"W, 14.322" CENTERS, SYNERGY
$36.55
B2 DWR1360B020 VERTICAL STEM SUPPORT, 3-HOLE, SYNERGY SEAT, B-1360-020
$25.30
B3 SCRSHFH1071 SCREW, SHFH, BLACK ZINC, 5/16-18 X 0.875", GR 8, W/PATCH
$2.81
B4 DWR1360B021 SEAT PAN STAND-OFF, SYNERGY SEAT, B-1360-021
$19.68
B5 SCRASBH1101 SCREW, BHSCS, BLACK ZINC, 10-32 X 1.75"
$2.81
B6 NUTNYLK1001 NUT, NYLOCK, BLACK ZINC, 10-32
$2.96
