Loading... TiLite YGS

Heel Loops

Name: TiLite YGS: Heel Loops
Manufacturer: TiLite
Heel Loops parts diagram
(Click on image to enlarge)

HEEL LOOP ASSEMBLY CHAIR WIDTH 0" OFFSET CHAIR WIDTH 1" OFFSET
AS102779-Z 18"-19" 20"

HEEL LOOP ASSEMBLY CHAIR WIDTH 0" OFFSET CHAIR WIDTH 1" OFFSET
AS102776-Z 12"-13" 14"-15"

HEEL LOOP ASSEMBLY CHAIR WIDTH 0" OFFSET CHAIR WIDTH 1" OFFSET
AS102778-Z 16"-17" 18"-19"

HEEL LOOP ASSEMBLY CHAIR WIDTH 0" OFFSET CHAIR WIDTH 1" OFFSET
AS102777-Z 14"-15" 16"-17"

Pos. Part # Description Price Buy
1 CP102129 HEEL LOOP POST, NYLON
$1.35
3 CP102250 HEELSTRAP, VELCRO 11" x 2"
$16.00
3 CP102251 HEELSTRAP, VELCRO 12" x 2"
$16.00
3 CP102252 HEELSTRAP, VELCRO 13" x 2"
$16.00
3 CP102253 HEELSTRAP, VELCRO 14" x 2"
$16.00
2 HD100345 #10 x 1.75" LONG PAN HEAD PHILLIPS
$1.37
