Electronics Assembly - Console (ka Internet/rah 52)

Name: Sc52 Sc52 Sonic: Electronics Assembly - Console (ka Internet/rah 52)
Manufacturer: Pride Mobility
Electronics Assembly - Console (ka Internet/rah 52) parts diagram
(Click on image to enlarge)

Top-level shroud assemblies contain illustrated raw shrouds designated with corresponding lower-case extensions. Raw shrouds are not available individually. The assembly must be purchased. Parts without lower-case extensions will be include
Pos. Part # Description Price Buy
A1 ELEASMB3793 ELECTRONIC, ASSY, TOP CONSOLE, W/RABBIT & TURTLE PRINTING, SC40U/SC44U, H-9975-006 N/A Please Call
B1a - B3 SHDASMB3636 SHROUD, ASSY, CONSOLE BOTTOM, RED, SOLID COLOR SC40 N/A Please Call
B1a SHDRAWM2223 SHROUD, BOTTOM CONSOLE, RED, SOLID COLOR SC40, {E-9955-013} N/A Please Call
B1b - B3 SHDASMB3637 SHROUD, ASSY, CONSOLE BOTTOM, BLUE, SOLID COLOR SC40 N/A Please Call
B1b SHDRAWM2224 SHROUD, BOTTOM CONSOLE, BLUE, SOLID COLOR SC40, {E-9955-013} N/A Please Call
B2 SCRPPH1094 SCREW, PPH, BLACK ZINC, M3 X 10MM, AB SELF THREADING N/A Please Call
B3 SCRPPH1021 SCREW, PPH, BLACK ZINC, M3-.5 X 10MM
$2.96
C1 - C2 FRMASMB2821 STANDARD PARTS, ASSY, LEVER, THROTTLE CONTROL
$35.10
C1 DWR9998B017 WIG WAG, REVO, B-9998-017 N/A Please Call
C2 SCRSETS1007 SCREW, SET, M4-.7 X 6MM N/A Please Call
D1 ELEASMB3866 ELECTRONIC, ASSY, THROTTLE POT, W/ISO RESISTOR, SC40U/SC44U N/A Please Call
