Loading...Sc300 Sc300 Legend

Shroud Assembly - Front 3 Wheel Gen 2

Name: Sc300 Sc300 Legend: Shroud Assembly - Front 3 Wheel Gen 2
Manufacturer: Pride Mobility
Shroud Assembly - Front 3 Wheel Gen 2 parts diagram
(Click on image to enlarge)

Applicable to Serial Number L-31000 through units manufactured prior to March 2000.
*A1  Painted shrouds are not available individually. The assembly must be purchased.
Pos.Part #DescriptionPriceBuy
A1 - A11SHDASMB1493SHROUD, ASSY, FRONT BODY, CHAMP97, LEGEND, SERIAL # >31000N/APlease Call
A1SHDASMB1494SHROUD, ASSY, FRONT BODY, CHAMP97, LEGENDN/APlease Call
A2PROMATT1000MAT, FLOOR, 3 WHEEL LEGEND/CELEBRITY STYLEN/APlease Call
A3PROMATT1003MAT, BATTERYN/APlease Call
A4PROSCUF1000MAT, SCUFF GUARD, CLEAR, 15"LN/APlease Call
A5PROSCUF1001MAT, SCUFF GUARD, CLEAR, 6.5"N/APlease Call
A6PLSXTRE1000RATCHET FASTENER, BLACK, NYLON, M8 HOLE SIZE X 15MM LN/APlease Call
A7PROMLDG1055TRIM, BLACK, 1"W X 63"LN/APlease Call
A8SCRPFH1026SCREW, PFH, BLACK ZINC, 10-32 X 1 1/2"N/APlease Call
A9DWR9950C011STRAP, 1" X 13.25", BATTERY, (PART A),WITH BUCKLE, C-9950-011N/APlease Call
A10DWR9950C012BATTERY, STRAP, 1" X 18", (PART B),WITH VELCRO HOOK & LOOP, C-9950-012N/APlease Call
A11DWR9000B034BATTERY, 16" X 1.6" X .75", CLIP, TIE DOWN, STRAP, B-9000-034N/APlease Call
