Wiring Loom - Power Seating

Name: Quantum 6400z: Wiring Loom - Power Seating
Manufacturer: Pride Mobility

(Click on image to enlarge)

Pos.	Part #	Description	Price	Buy
A1	FRMASMB8821	MOUNT BRACKET, ASSY, POWER SEAT, QUANTUM6000	$22.05
B1	FRMASMB8818	FRAME, ASSY, FRONT STABILIZER SECTION, QUANTUM6000, POWER SEAT	$11.81
