The RAZ Design RAZ-AT tilting shower commode chair tilts up to 40 degrees to provide extra pressure reduction and user comfort. The unique frame design utilizes lockable gas springs that help lift the seat to an upright sitting position, making the RAZ-AT one of the easiest tilting rehab shower chairs to operate.
The RAZ-AT rehab shower chair...
Tilt frame tilts to 40 degrees for extra pressure reduction and positioning comfort. Easy for caregivers to tilt and maneuver. Pressurized springs also help lift frame back into the upright position.
Adjustable pivot posts allow floor to seat height adjustments from 21" - 25" easily.
Standard headrest is easy to adjust without tools. Also available is a large adjustable headrest.
Contoured for pressure reduction and pelvic stability the soft integral-skin foam for comfort and durability is available with open or bridged front.
Available sizes:
Tilt Function: | Gas spring assisted Up to 40° tilt range |
Seat Width: | 18" |
Seat Depth: | 16" or 19" |
Seat Adjustment: | Up to 2" (fore/aft) |
Seat Height (front seat to floor): | 21" - 25" |
Clearance Height (under seat): | 12.5" - 16.5" w/ pan |
16.5" - 20.5" w/o pan | |
18.75" - 22.75" w/o pan bracket | |
Back Type - Standard w/ Fixed Ht, Flip-Up Arms: | 17" back ht. (Z505) |
20" back ht. (Z514) | |
Back Type - Optional w/ Adj. Ht/Angle, Flip-Up Locking Armrests: | Adjusta-Back |
17" back ht. (Z510) | |
20" back ht. (Z515) | |
24" back ht. (Z520) | |
Armrest Height: | 8.5" (Z505) |
9.5" (Z514) | |
7" - 9.5" (Z510) | |
8" - 10.5" (Z515) | |
Width between Armrest Pads: | 18.5" |
Lateral Adjustment: | 2" vertical, 1" fore/aft 0.5-1.5” offset, +/- 10° angle |
Footrest Adjustment (from seat to footplate): | 16" - 20.5" |
Catser Type and Size: | Four dual-locking 5" casters |
Overall Width: | 23" w/ std. arm pad |
25.5" w/ Z715 arm pad | |
Overall Length w/ Footrests | 45.3" |
Overall Length w/o Footrests | 33.6" |
Weight Capacity: | 300lbs. |
Product Weigth: | 65lbs. |
Frame Material and Hardware: | Stainless Steel |
Warranty | Two year limited warranty on the frame against manufacturing defects. |
One year on all other components subject to normal wear and tear exclusions. |
